MD11 Surgical Motor System without Handpiece (2003)

MSRP: $4,150.00
$2,900.00
(You save $1,250.00 )
(No reviews yet) Write a Review
SKU:
PST-NOUV-2003
  • Developed with the intention to put extra smoothness into your hands.
  • Improved electronic motor and a sophisticated motor control are key players in this new generation of Nouvag motor systems
  • New design with smooth edges for easy cleaning and a display that gives you all the information at a glance
  • Single function keys with haptic and audible feedback guarantee for accurate device setup
  • Inserting and changing of tube sets is carried out effortlessly by a front access push button and tube compartment
  • The tube bracket swings open and gives good view to the tube seat and the two notches to fix the tube in
  • A broad variety of extensions and accessories is provided by Nouvag AG and can anytime be added.

Advantages

  • Sophisticated motor control for smooth and precise power delivery in any range of speed
  • Motor speed range of 300 – 40,000 rpm. 70 Ncm of maximum torque at the 20:1 Contra Angle with graphical, real time torque control
  • Sturdy, high quality architecture and finish
  • Integrated pump system for cooling the instrument to prevent of tissue damage
  • 3 programs for drilling, cutting threads, screwing in the implants and placing the cover screw

Technical Data

  • Voltage - 100/115/230 Volt at 50 – 60 Hz
  • Max. output power/motor torque - 120 W/6 Ncm
  • Speed range, motor -300 – 40,000 rpm
  • Max. torque at the instrument - 70 Ncm, 20:1 Contra Angle
  • Attachment of instruments - ISO 3964 connector (DIN 13940)
  • Cable length of motor - 2 meters
  • Coolant flow rate - 1 – 100 ml/min
  • Dimensions, W x D x H - 260/250/110 mm
  • Weight, control unit - 2.8kg
  • Foot control - Vario foot pedal
